Description
The Multiquip MTR40HF is a lightweight, gas-powered rammer designed to compact soil in small or tight spaces. With 4,505 lbs. of force and a narrow shoe, it’s perfect for trenches, foundations, and utility work. It runs on a proven Honda GX100 engine that starts easily and works reliably on every job. This rammer is built for both power and comfort. It delivers strong compaction with less noise and vibration, helping operators work longer without fatigue. The multi-stage air filter protects the engine and cuts down on maintenance. If you need a dependable, compact rammer that’s easy to move and use, the MTR40HF is a top choice.
Highlights:
- 4,505 lbs. impact force
- 10.6″ x 5.9″ narrow shoe
- Lightweight and portable – only 101 pounds (46 kg)
- Grease lubricated design eliminates making it ideal for narrow trenches
- Reliable 4-stroke Honda GX100 engine for reliable starting
- Ideal for landscapers, electrical contractors and plumbing contractors
- Redesigned fuel tank to meet EPA standards for evaporative emissions
- Built-in roller and lift handle for easy transport
- Optional foot extensions available for trench work
| Unit Specifications | ||
|---|---|---|
| Blows Per Min. | 699 | |
| Impact Force | 1215 lbf | 5.4 kN |
| Shoe Jump Height | 2.2 in | 55 mm |
| Shoe Dimensions (LxW) | 10.6 x 5.9 in | 270 x 150 mm |
| Travel Speed Per Min. | 30 ft | 9 m |
| Fuel Tank Capacity | 2.1 qt | 2 L |
| Dimensions & Weights | ||
| Overall Length | 24.5 in | 622 mm |
| Overall Width | 13.8 in | 351 mm |
| Overall Height | 43.7 in | 1110 mm |
| Operating Weight | 101 lb | 46 kg |
| Shipping Weight | 107 lb | 49 kg |
| Engine Specifications | ||
| Engine Make/Model | Honda GX100 | |
| Start Method | Recoil | |
| Engine Power | 3.0 HP | 2.2 kW |
| Engine RPM | 4100 | |
| Fuel Type | Gasoline |
