Description
The Wacker Neuson PTS4V Trash Pump is built to handle the dirtiest water jobs. With a 4-inch intake and discharge, it moves up to 540 gallons per minute, making it perfect for clearing water with sludge, mud, or debris up to 2 inches wide. The strong cast-iron parts last through harsh use, while the Honda GX390 engine keeps it running smooth and steady. A heavy-duty frame protects the unit, and a clean-out port lets you maintain it fast. Vibration isolators keep the pump steady on rough ground.
Key Features:
- 4″ suction & discharge ports – pumps up to 540 GPM
- Passes solids up to 2″ – ideal for dirty water and debris
- Powered by a Vanguard gasoline engine – dependable and fuel-efficient
- Cast-iron volute & impeller – built for tough jobs
- Heavy-duty roll cage – protects pump and engine
- Quick clean-out port – fast and easy maintenance
- Vibration isolators – reduces movement during use
| Engine | ||
|---|---|---|
| Engine Make | Briggs & Stratton | |
| Engine Model | Vanguard 305447 | |
| Power Rating Max. | 11.9 kW | 16.0 HP |
| Rated Speed | 3600 RPM | |
| Engine Type | 2 Cylinder, 4-cycle, Gasoline Engine | |
| Cooling Type | Air Cooling | |
| Air Cleaner Type | Dry Air Filter | |
| Fuel Management | Carburettor | |
| Fuel Type | Regular Unleaded Gasoline | |
| Fuel Tank Capacity | 17.0 L | 4.5 gal (US) |
| Oil Specification | SAE 10W-30 (or SAE 5W-30 above 5°C) | |
| Oil Volume (incl. filter) | 1.3 L | 0.3 gal (US) |
| Spark Plug | RC12YC | |
| Starter Type | E-Starter, Recoil Starter | |
| Starter Voltage | 12 V | |
| Battery Size | BCI Group 22NF | |
| Battery Start Current | 32 A | |
| Battery Cold-Start Current | 230 A | |
| Cylinder | 2 | |
| Cylinder Capacity | 479 cm³ | 29.2 in³ |
| Exhaust-Gas Limit | PDB_09_00034_01 | |
| Fuel Consumption | 5.40 L/h | 1.4 GPH (US) |
| Run Time at Speed | 13.2 h | 3.2 h |
| Mechanical – Output Details | ||
| Flow Rate Max. | 2,322 L/min | 613.4 gal/min |
| Suction Head Max. | 7.6 m | 24.9 ft |
| Solid Diameter Max. | 50.0 mm | 2.0 in |
| Delivery Height Max. | 24.0 m | 78.7 ft |
| Pump Pressure Max. | 3.1 bar | 45.0 psi |
| Mechanical Details | ||
| Operating Weight | 150.0 kg | 330.7 lb |
| Length | 915 mm | 36.0 in |
| Width | 890 mm | 35.0 in |
| Height | 890 mm | 35.0 in |
| Intake/Pressure Socket Diameter | 100 mm | 3.9 in |
| Shipping and Storage | ||
| Shipping Width | 750 mm | 29.5 in |
| Shipping Height | 1800 mm | 70.9 in |
| Shipping Length | 1150 mm | 45.3 in |
